# Scaling and Eigenmode Tests of the Improved Fat Clover Action

###### Abstract

We test a recently proposed improved lattice-fermion action, the fat link clover action, examining indicators of pathological small-quark-mass lattice artifacts (“exceptional configurations”) on quenched lattices of spacing 0.12 fm and studying scaling properties of the light hadron spectrum for lattice spacing and 0.16 fm. We show that the action apparently has fewer problems with pathological lattice artifacts than the conventional nonperturbatively improved clover action and its spectrum scales just as well.

###### pacs:

^{†}

^{†}preprint: Preprint numbers: UUHEP 99/1

## I Introduction

The goal of lattice fermion improvement schemes is to increase the effectiveness of computer algorithms by significantly reducing lattice artifacts at economically coarse lattice spacings, particularly in the range fm. The clover action with the clover coefficient chosen nonperturbatively [1] (NPCA) has been found to give a substantially better scaling of the hadron spectrum over the range fm than the conventional Wilson fermion action (WA) [2, 3]. However, as the lattice spacing is increased over this range, the NPCA becomes increasingly sensitive to local fluctuations in the gauge configurations that produce unwanted artifact singularities at small, positive quark mass, the so-called “exceptional configurations.” To avoid them, one must keep the quark mass artificially high. At increasingly coarse lattice spacing, the lower bound on “safe” quark masses rises, making an extrapolation to physical quark masses increasingly problematical. Difficulties with such “exceptional” configurations are overcome in a variety of approaches, including pole shifting [4] and schemes which implement an exact chiral symmetry on the lattice, the overlap formalism [5], and the domain wall approach [6]. Such methods are computationally expensive. Here, we consider a new (approximate) improvement scheme, the “fat clover” action.

The “fat clover” action (FCA), proposed by DeGrand, Hasenfratz, and Kovács [7], couples the standard clover action to a locally smoothed gauge field. Smoothing of the gauge fields is achieved through a series of APE blocking steps [8]. It is intended that the number of blocking steps remains fixed as the continuum limit is approached. Thus the fermion-gauge coupling is modified at a scale that is a fixed multiple of the cutoff, and the correct local action is recovered in the limit. Smoothing has a number of beneficial effects: lattice artifacts are suppressed, chiral properties are improved, and the renormalization of a variety of lattice quantities, such as the local-vector-current and axial-vector-current renormalization constants and , is small [7, 9].

Here we examine two variants of fat link actions: one using the tree level value for the strength of the clover term (TFCA) and one using an optimized value (OFCA). (See Table 1 for a guide to our abbreviations.)

We first study the distribution of real eigenmodes of the lattice Dirac operator in an ensemble of gauge configurations, with particular attention to the “exceptional” eigenvalues at positive quark mass. We show that the FCA has improved chiral properties, in the sense that the spread of leading near zero modes is narrower than with the NPCA at a lattice spacing of fm. Thus the “safe” lower bound on quark masses is lower with the FCA. We then present a study of fluctuations in the pion correlator as a qualitative test of the suppression of exceptional configurations in NPCA and TFCA.

Finally we perform a small scaling test of the quenched hadron spectrum for the TFCA and OFCA. Scaling is tested as the lattice constant is varied from fm to fm, choosing some fixed value of the quark mass, such that either , where is the string tension, or [7]. Included for comparison are the corresponding results for the standard Wilson action (WA), nonperturbative clover action (NPCA), and the standard Wilson action on a fat link background (FWA). In this scaling study we pay careful attention to the elimination of a variety of sources of systematic error: we scale all quantities with physical dimensions and fix the lattice dimensions in physical units.

## Ii Computational Method

### ii.1 Fat Clover Action

The fat clover action (FCA) is the usual clover action

(1) |

where is the Wilson action, and is the standard “clover” expression for the field strength tensor , except that all link variables in and are fat links. The fat link is constructed from the original (“thin”) links with a series of APE blocking steps [8]. A single step creates a new gauge configuration with each gauge link replaced by a weighted sum of the link and its staples, followed by a projection back to SU(3). Explicitly, each link is replaced by

(2) |

where represents the projection, which in SU(3) chooses the unique group element of SU(3) maximizing . (Replacement occurs after all smooth links for the lattice are computed.) This process is repeated times in our study with a coefficient . Such a choice was found to give good stability in instanton size and placement during smoothing in both SU(2) and SU(3) [10, 11]. We have not explored other choices extensively, but suspect considerable latitude is permitted in the choice of and . After smoothing, the mean plaquette of the fat link is close to 1: For , the mean plaquette is and for it is .

Fat link clover actions, like all clover actions, have no nor corrections as long as the clover coefficient is taken to approach unity in the limit. In perturbation theory[12] the effect of the fat link is to multiply the usual thin link quark-gluon vertices by a form factor with , where is the gluon momentum. This easily accounts for the observed considerable reduction in additive quark mass renormalization and finite renormalization constants for vector and axial currents close to unity.

The clover coefficient is a priori unspecified. We expect, based on the near unit value of the mean plaquette, that an optimal value for simulations would be close to the tree-level value of unity, and that is what one would choose in a tadpole-based improvement program[13]. We chose the value of using the approach of DeGrand, Hasenfratz and Kovaćs, based on the position of real eigenmodes of the Dirac operator [7].

To locate the real eigenmodes, for each configuration we calculated a noisy estimator of the expectation value [7, 14, 15]

(3) |

at a closely spaced series of real values , where is an arbitrary random vector, held constant for the scan over . A real eigenvalue of appears as a pole in , provided the corresponding eigenvector has nonzero overlap with the vector . The quantity would also diverge at a real eigenvalue of , but since the real eigenmodes of are also close to being eigenmodes of with eigenvalue , the factor helps to distinguish them.

In the continuum limit the only real eigenvalues of are chiral zero modes, occurring at , i.e. zero bare quark mass. If the lattice Dirac operator is not chiral, the real modes are spread around (defined as the value of where extrapolates to zero), and can also be shifted from the chiral value. Such real eigenmodes are undesirable lattice artifacts that prevent lattice simulations at small quark mass. [16]. Configurations that produce them are called “exceptional”, although the problem really lies with the choice of fermion action and not with the gauge configuration itself. Actions with improved chiral properties have real eigenmodes that cluster more closely around . For such actions it should be possible to study lower quark masses without encountering difficulties with exceptional configurations, or to carry out a simulation on a coarser lattice at the same quark mass.

For a sufficiently high degree of fattening one can optimize the clover coefficient by minimizing the spread of the real eigenmodes on Monte Carlo-generated configurations. In this work, however, we choose a simpler approach. We generate a series of artificial lattice instantons of varying size on lattices and of size on lattices. Instanton studies at and predicted instanton sizes in this range [17]. For each such gauge configuration, we examined the position of the resulting fermion real eigenmode. Results are shown in Tables 2 and 3 and Fig. IV. For large the near-zero modes are quite close to zero quark mass. As drops below the lattice cutoff, the would-be zero mode moves toward negative quark mass. The trajectory of real eigenmodes is altered by adjusting the clover coefficient . We find that with the variation in pole position is minimized for instanton sizes in the range . With the variation in pole position is minimized for . Since our scaling test considers lattices over a range of spacings varying by a factor of 2, we choose for our coarsest lattice spacing and for our finest lattice spacing to assure scaling consistency. We call the action with tuned clover coefficient the “optimized fat clover action” (OFCA). To test sensitivity to this choice, we also present results with the tree-level choice (TFCA).

### ii.2 Computational Parameters

There are two parts to this study: an analysis of the distribution of low energy real eigenvalues and an analysis of the scaling of the spectrum. For studies of the distribution of near-zero eigenvalues at we analyzed 100 configurations of size , and for the companion spectrum study to relate the pion mass to the value, 20 configurations of size . For the spectrum scaling studies we have worked with two ensembles of quenched gauge configurations generated with the conventional one-plaquette Wilson action: 120 configurations of size at and 100 of size at , corresponding to lattice spacing and fm, respectively, based on recent measurements of the string tension for this action in lattice units [18] and the choice MeV [19].

The lattice dimensions for the scaling study were chosen to keep an approximately constant physical volume, so as to avoid inconsistent finite size effects. To allow tuning of the quark mass, either by fixing the pion mass in terms of the string tension or in terms of the rho mass, we calculate the spectrum for (typically) three neighboring values selected so that the desired dimensionless ratios can be reached by interpolation. Quark propagators were generated from a fixed Gaussian (shell-model) source with standard deviation for the coarsest lattice and for the finest. Our scaling tests were computed at three values of the clover coefficient for each gauge coupling: or 1.2, as noted above, for the OFCA, for the tree-level fat clover action (TFCA), and for the fat Wilson action (FWA) to test the relative merits of smoothing and reducing the O(a) errors in the action.

## Iii Results

### iii.1 Fermion eigenmodes

For each of the actions in our study we determined the distribution of the real eigenmodes on a set of 100 gauge configurations, generated with the conventional single plaquette action at . We determined the probability distribution of the leading pole (i. e. the eigenvalue corresponding to the largest quark mass) for the various actions in our study.

Note that this statistic is different from the eigenvalue histograms of Ref. [7], where all the low energy eigenmodes were included to study the spread of the physical modes. Since here we consider only the pole corresponding to the largest mass on each configuration, these plots are indicative of the exceptional configurations.

To compare leading-pole distributions from the various actions, we converted the values to values, by measuring the hadron spectrum with the same action on a set of 20 quenched configurations. Results are shown in Fig. LABEL:fig:prob_leading. Pion masses used for constructing the linear scale conversion, are given in Tables 4 and 5. The bin widths in this figure are variable, since the poles were located by scanning at the same constant increment in for all actions. We took this interval as the resolution of the pole location. The corresponding interval in , however, varied from action to action. The bin heights are scaled so that the probability distributions all have unit total area. The TFCA and OFCA actions clearly produce distributions that are more sharply clustered around . The peak for the OFCA appears at a nonzero bin in , but we estimate a combined systematic and statistical error (one sigma) of one bin width arising from the conversion from to near zero pion mass.

To put these results in another perspective, we have also measured the ratio for these configurations. For our sample of gauge configurations at the NPCA encounters its first pole at , the TFCA, at about 0.37(6) and the OFCA at about 0.42(5).

### iii.2 Pion Correlators

While a pole in the quark propagator at is the most precise indicator of an exceptional configuration, fluctuations in a hadron correlator, e.g. the pion correlator, give a qualitative indication. Poles in the quark propagator typically have residues with concentrated support in Euclidean space-time. For instanton-induced poles, localization of the residue comes from localization of the zero eigenmode. Since the pion propagator is the gauge-invariant square of the quark propagator, a nearby exceptional pole typically contributes a strong localized fluctuation in the pion correlatorin some cases inducing a “W” shape in a semilog plot.

Starting from a common sample of 80 quenched single-plaquette gauge configurations at , we compute the pion correlator for the NPCA and TFCA for a range of quark masses. We then consider two measures of fluctuations: (1) the noise to signal ratio of the correlator at a fixed time and (2) the number of outliers, based on a correlated chi square measure.

The simplest measure of fluctuations is the noise to signal ratio in a correlator, namely the ratio of the standard deviation of a correlator to the value of the correlator, , as a function of distance and/or quark (or pion) mass. The pseudoscalar correlator is the most useful one to look at, since simple theoretical arguments suggest that should be roughly independent of the quark mass. In Fig. LABEL:fig:noise_to_signal this ratio at , namely , is plotted over a range of for the NPCA and TFCA. It is clear that for , fluctuations are dramatically reduced with the TFCA.

We denote the correlator on the th configuration by and its mean over the sample of configurations by . For the outlier test we start by constructing the usual covariance matrix , based on the observed fluctuations, and its inverse . The correlated chi square measure for configuration is then

(4) |

for degrees of freedom. The corresponding confidence level is then used to determine the strength of deviation from the mean. For the sample of 80 configurations we treated the two time intervals and separately. A configuration was deemed exceptional, if the confidence level determined on either interval was less than , a somewhat arbitrary value that was chosen to correspond to strongly discernible deviations, many of them with the “W” shape, characteristic of an exceptional configuration. Note that a Gaussian normal fluctuation at this level in a sample of 80 would be expected only once in about trials. The process of identifying outliers was carried out iteratively, in each pass removing the outliers from the sample as they were identified, until none remained. Results are summarized in Tables 6 and 7. Based on this measure, if we were to insist on no more than one exceptional configuration in a sample of this size at , the NPCA would be restricted approximately to and the TFCA to .

### iii.3 Spectrum

Correlators for the zero momentum pion, rho, nucleon, and were fit to single exponential forms, minimizing the correlated . Care is needed to prevent biases arising from the choice of the fitting range, particularly from the choice of minimum time . We used two methods to test for bias: In fitting correlators for a set of closely spaced values we selected (1) the smallest giving a minimum CL for all ’s greater than 0.05 and an average CL greater than 0.1; and (2) the for which the product of CL and the number of degrees of freedom (df) is maximum, a rather ad hoc rule of thumb [20]. As a rule both methods gave the same . Where a different value was obtained, we determined that the variation in mass value was within the statistical errors of the fits.

We found that for the lattice was generally half the value on the lattice. In the few cases in which it was not (the rho meson for OFCA and TFCA), we verified that, had we enforced this further condition, the central mass value would have shifted by less than 1%, an amount smaller than the error in the observed scaling violation. Our fitting range is then approximately constant in physical units, and our results are therefore free of bias from this source.

We also checked the single exponential fits against two-exponential fits and verified that the results were stable within statistical errors. Results of the fits are shown in Table 8.

We consider two alternatives for fixing the quark mass: (1) fixing and (2) fixing . These values were chosen to correspond to each other, approximately. Since variations in the strength of the clover term changes the and mass splittings, so can change the pi to rho mass ratio at fixed physical quark mass, the former method is preferable. We present the second, more popular, method to allow comparison with other work.

Table 9 and Figs. LABEL:fig:scalingpimasses and LABEL:fig:scalingpiratios show the masses of particles and their ratios at and the scaling violations from to . For comparison, conventional Wilson data (WA) from recent calculations are shown. The WA values are interpolated from raw data given in Ref. [21]. The WA values are interpolated from raw data given in Refs. [22, 23]. The value is slightly outside the range of values given in Ref. [22], so to avoid extrapolation, those data were supplemented by data given in Ref. [23]; however, extrapolation from the data of Ref. [22] alone gives the same results. The NPCA values were interpolated from unpublished values provided by Heller [24]. The NPCA values are from Ref. [2].

The mass of the rho meson is seen to be a sensitive indicator of scaling violations. The scaling violation in the rho mass is reduced from approximately 7% for the WA to less than 2% for the OFCA and TFCA. Fattening the WA does not improve scaling with any significance. Thus smoothing of the gauge fields alone does not improve scaling. This is because the Wilson action, with either thin or fat links, has lattice artifacts which are removed by the addition of the clover term. (A similar behavior for a fat link action without a clover term, in that case, a hypercubic action, was also seen in Ref. [25].)

Scaling violations of the nucleon mass are statistically consistent for all the actions considered. Scaling violations of the delta mass are improved from roughly 8% for the FWA to less than 4% for the TFCA and OFCA. This also is found for the alternative fits of the delta masses, suggesting that the scaling improvement seen is real, despite potentially large systematic errors in the fits of the delta masses.

We extrapolated the mass values to zero lattice spacing, forcing a common extrapolated mass for all actions. Our extrapolation is linear in for the WA and FWA and linear in for the OFCA, TFCA and NPCA. Results are plotted in Figs. LABEL:fig:scalingpimasses and LABEL:fig:scalingpiratios. It is clear that none of the actions completely remove scaling violations in the nucleon or delta mass, but that all of the clover actions show smaller violations than the Wilson actions.

For the second approach we adjust quark masses so as to fix the ratio . Table 10 shows the masses of particles and their ratios, and the scaling violations from to . For comparison, conventional Wilson data from recent calculations are shown. The Wilson values are interpolated from raw data given in Ref. [21]. The Wilson values are interpolated from raw data given in Ref. [22]. Also shown are data for the TFCA and NPCA. For the NPCA the values are given in Ref. [3], already interpolated to . The values at are from Ref. [2].

The mass of the rho again is seen to be a sensitive indicator of scaling violations. For the pair of lattice spacings used, the scaling violation of the rho mass is reduced from approximately 13% for the conventional WA to less than 2% for the OFCA or the TFCA. There is no significant scaling improvement of the rho mass for the FWA compared with the WA. The scaling violations of the rho are compounded with those required by the fixing of the pion to rho mass ratio to the same constant for all cases. The quark masses are forced to values at and such that the scaling violation of the pion mass equals that of the rho mass. This roughly doubles the total rho scaling violation at fixed , compared with that for fixed , for cases where scaling violations in the pi-rho mass splittings are large, as will be shown to be the case for the Wilson actions.

Scaling violations of the nucleon mass also are compounded with those required by the fixing of the pion to rho mass ratio to the same constant for all cases. The value of the nucleon mass is lowered similarly to the pion mass by the clover (magnetic moment) term, so forcing the scaling violation of the pion mass to equal that of the rho mass also forces the nucleon mass to acquire a similar scaling violation. At , scaling violations of the nucleon mass are reduced from approximately 10% for the WA and FWA to approximately 5% for the TFCA to approximately 2% or lower for the OFCA.

Scaling violations of the delta mass are improved from roughly 14% for the FWA to less than 5% for the OFCA.

Mass splittings are given in Table 11 at . Phenomenological values of the differences of the squared masses of vector and pseudoscalar particles are almost equal for different quark flavors, so the unrealistically high quark mass used in the lattice calculations should not matter much. Similarly, the difference of the masses of spin and spin baryons are comparable for different flavors. Scaling violations of the mass splittings are reduced substantially for the clover actions compared with the Wilson actions. Also there is rough agreement with experimental values for the clover actions. The experimental values are MeV and MeV. Using MeV, we have and .

In summary, the proposed fat clover actions with either tree-level clover coefficient (TFCA) or optimized clover coefficient (OFCA), have greatly improved scaling properties compared with the Wilson action. The scaling improvement with either of these actions is comparable to that of the NPCA. Scaling tests of the FWA show that smoothing by itself does not improve scaling. The combination of the clover term with a fat link allows one to reach smaller values of the pseudoscalar mass than is possible with the NPCA, with an apparently equivalent level of scaling violations.

## Iv Conclusions

Using a common set of gauge configurations, we have carried out a systematic study of the distribution of leading near-zero eigenvalues and the scaling of the light hadron spectrum and for a variety of fermion actions on quenched lattices with lattice spacing in the range fm. Actions included in this study are the conventional Wilson action (WA), Wilson action on fat gauge links (FWA), clover action with a non-perturbatively tuned clover coefficient (NPCA), tree-level “fat” clover action (TFCA) and optimized fat clover action (OFCA). All of the clover actions show better scaling behavior than any of the Wilson actions–an entirely expected result, since adding the clover term with the correct coefficient converts an action into an one. Based on an analysis of pole positions, we have found that the fat clover actions OFCA and TFCA exhibit chiral properties superior to the NPCA, WA, and FWA. A further analysis of fluctuations in the pion correlator shows that the TFCA is far less noisy than the NPCA, a further circumstantial indication of a suppression of exceptional configurations.

###### Acknowledgements.

We thank Urs Heller for providing us with unpublished results for the nonperturbative clover action and for a careful reading of the manuscript. This work is supported in part by the U.S. National Science Foundation under grants PHY 96–01227 and PHY 99–70701 and by the U. S. Department of Energy under contract DE-FG03-95ER40894. Computations were carried out with grants of computer time for the T3E at the San Diego Supercomputer Center and for the IBM SP at the University of Utah Center for High Performance Computing.## References

- [1] M. Lüscher, S. Sint, R. Sommer, and P.Weisz, Nucl. Phys. B478, 365 (1996).
- [2] M. Gockeler et al., Phys. Rev. D 57, 5562 (1998).
- [3] R.G. Edwards, U.M. Heller, and T.R. Klassen, Phys. Rev. Lett. 80, 3448 (1998).
- [4] W. Bardeen, A. Duncan, E. Eichten, G. Hockney and H. Thacker, Phys. Rev. D57, 1633 (1998)
- [5] R. Narayanan and H. Neuberger, Nucl. Phys. B 443, 305 (1995).
- [6] D.B. Kaplan, Phys. Lett. B 288, 342 (1992); Nucl. Phys. B 30 (Proc. Suppl.), 597 (1993); R. Narayanan and H. Neuberger, Phys. Lett. B 302, 62 (1993); Phys. Rev. Lett. 71, 3251 (1993); Nucl. Phys. B 412, 574 (1994); Y. Shamir, Nucl. Phys. B 406, 90 (1993); V. Furman, and Y. Shamir, Nucl. Phys. B 439, 54 (1995).
- [7] T. DeGrand, A. Hasenfratz, and T. Kovács, Nucl. Phys. B547, 259 (1999).
- [8] M. Falcioni, M. Paciello, G. Parisi, B. Taglienti, Nucl. Phys. B 251 [FS13], 624 (1985); M. Albanese et al., Phys. Lett. B 192, 163 (1987).
- [9] T. DeGrand, Phys. Rev. D60, 094501 (1999).
- [10] T. DeGrand, A. Hasenfratz, and T. Kovács, Nucl. Phys. B520, 301 (1998).
- [11] A. Hasenfratz, and C. Nieter Phys. Lett. B439, 366 (1998).
- [12] C. Bernard and T. DeGrand, hep-lat/9909083. (To appear in the Proceedings of Lattice 99).
- [13] G. P. LePage and P. Mackenzie, Phys. Rev. D48, 2250 (1993).
- [14] W. Bardeen, A. Duncan, E. Eichten, G. Hockney, and H. Thacker, Nucl. Phys. (Proc. Suppl.) B63, 141 (1998).
- [15] Y. Kuramashi, M. Fukugita, H. Mino, M. Okawa, and A. Ukawa, Phys. Rev. Lett. 72, 3448 (1994).
- [16] W. Bardeen, A. Duncan, E. Eichten and H. Thacker, Phys. Rev. D59, 014507 (1999).
- [17] Mark Stephenson, PhD Thesis (University of Utah, 1999).
- [18] R.G. Edwards, U.M. Heller, and T.R. Klassen, Nucl. Phys. B517, 377 (1998).
- [19] G. Bali, K. Schilling, and A. Wachter, Phys. Rev. D 56, 2566 (1997).
- [20] K. Bitar et al., Phys. Rev. D 42, 3794 (1990).
- [21] M. Fukugita, Y. Kuramashi, M. Okawa, and A. Ukawa, Phys. Rev. Lett. 75, 2092 (1995).
- [22] S. Aoki et al., Nucl. Phys. (Proc. Suppl.) B47, 354 (1996).
- [23] Y. Iwasaki et al., Phys. Rev. D 53, 6443 (1996).
- [24] U.M. Heller, private communication (1998).
- [25] T. DeGrand, Phys. Rev. D 58, 094503 (1998).

FCA | Clover action on fat gauge links (either optimized or tree-level). |

OFCA | Clover action on fat gauge links with optimized clover coefficient. |

TFCA | Clover action on fat gauge links with tree-level clover coefficient. |

NPCA | Conventional clover action with non-perturbatively tuned clover coefficient. |

FWA | Wilson action on fat gauge links. |

WA | Conventional Wilson action (). |

OFCA | TFCA | NPCA | |||
---|---|---|---|---|---|

FWA | WA | ||
---|---|---|---|

WA | |||||

5.7 | 0.815(5) | 1.596(11) | 1.929(21) | 3.075(36) | |

6.0 | 0.763(2) | 1.538(6) | 2.072(10) | 3.186(17) | |

6.4(0.6)% | 3.6(0.8)% | +7.4(1.3)% | +3.6(1.3)% | ||

FWA | |||||

5.7 | 0.823(11) | 1.604(30) | 1.921(26) | 3.082(59) | 3.362(60) |

6.0 | 0.768(11) | 1.587(21) | 2.055(23) | 3.261(31) | 3.631(62) |

6.6(1.7)% | 1.1(2.3)% | +7.0(1.9)% | +5.8(2.3)% | +8.0(2.7)% | |

TFCA | |||||

5.7 | 0.704(8) | 1.439(24) | 2.246(29) | 3.233(61) | 3.733(75) |

6.0 | 0.695(10) | 1.480(23) | 2.275(29) | 3.366(38) | 3.872(65) |

1.3(1.8)% | +2.8(2.4)% | +1.3(1.8)% | +4.1(2.3)% | +3.7(2.7)% | |

OFCA | |||||

5.7 | 0.678(9) | 1.408(29) | 2.334(34) | 3.285(66) | 3.814(80) |

6.0 | 0.684(10) | 1.462(24) | 2.310(30) | 3.384(39) | 3.922(68) |

+0.9(2.0)% | +3.8(2.7)% | 1.0(1.9)% | +3.0(2.4)% | +2.8(2.8)% | |

NPCA | |||||

5.7 | 0.671(8) | 1.432(20) | 2.356(30) | 3.375(52) | 3.854(87) |

6.0 | 0.674(2) | 1.488(9) | 2.345(12) | 3.490(23) | |

+0.4(1.2)% | +3.9(1.6)% | 0.5(1.4)% | +3.4(1.7)% |

WA | ||||

5.7 | 1.554(16) | 1.698(19) | 2.638(35) | |

6.0 | 1.514(8) | 1.924(10) | 2.913(17) | |

2.6(1.1)% | +13.3(1.4)% | +10.4(1.6)% | ||

FWA | ||||

5.7 | 1.547(38) | 1.710(27) | 2.646(62) | 3.024(71) |

6.0 | 1.548(24) | 1.905(24) | 2.952(33) | 3.463(61) |

+0.1(2.9)% | +11.4(2.3)% | +11.6(2.9)% | +14.5(3.4)% | |

TFCA | ||||

5.7 | 1.436(24) | 2.247(29) | 3.235(61) | 3.735(75) |

6.0 | 1.475(22) | 2.289(28) | 3.393(37) | 3.889(64) |

+2.7(2.3)% | +1.9(1.8)% | +4.9(2.3)% | +4.1(2.7)% | |

OFCA | ||||

5.7 | 1.422(26) | 2.383(33) | 3.393(64) | 3.893(76) |

6.0 | 1.475(22) | 2.349(29) | 3.465(38) | 3.968(65) |

+3.7(2.4)% | 1.4(1.8)% | +2.1(2.2)% | +1.9(2.6)% | |

NPCA | ||||

5.7 | 1.455(9) | 2.427(10) | 3.532(17) | |

6.0 | 1.466(18) | 2.380(17) | 3.488(34) | |

+0.8(1.4)% | 1.9(1.3)% | 1.2(1.1)% |

WA | ||

FWA | ||

TFCA | ||

OFCA | ||

NPCA | ||
